Hardware
CPU: 1.06GHz, 64bit@DDR533, with floating point
Memory: 512MB
Internal HDD1: 3.5" SATA(II) X1
Max Internal Capacity: 4TB (2x 2TB hard drives)
External HDD Interface: USB 2.0 port X3, eSATA port X1
Size: 160mm X 218mm X 88mm
Weight: 0.98kg
LAN: Gigabit X1
Fan: X1(70mmX70mm)
Noise Level:2 24dB(A)
Power Recovery
AC Input Power Voltage: 100V to 240V
Power Frequency: 50Hz to 60Hz, Single Phase
Max Supported IP Camera: 107 (See All Supported IP Cameras)
Operating Temperature: 5°C to 35°C (40°F to 95°F)
Storage Temperature: -10°C to 70°C (15°F to 155°F)
Relative Humidity: 5% to 95%RH
Maximum Operating Altitude: 10,000 feet
Power Consumption3
30W(Access);
14.4W(Hibernation)
Certification
FCC Class B, CE Class B, BSMI Class B
Networking Protocols
CIFS
AFP (3.1)
FTP
NFS
Telnet/SSH
Windows ADS Domain Integration
ADS Support
Domain users login via Samba/AFP/FTP
Synology Data Replicator 3 for Domain Users
Security
"FTP over SSL (explicit)" or "FTP over TLS (explicit)"
FTP Auto-Block
Encrypted Network Backup
Encrypted rsync
HTTPS Connection
File System
EXT3
FAT (External Disk Only)
NTFS (External Disk Read Only)
File Sharing
Max User Accounts: 2,048
Max Groups: 256
Max Shared Folder: 256
Max Concurrent Connections(SAMBA, FTP, AFP): 256
Utilities
Synology Assistant
Synology Data Replicator 3
Synology Download Redirector
Add printer wizard |
Applications
Surveillance Station 2
Photo Station 3
File Station 2
Audio Station
Web Station
PHP/MySQL
Download Station 2
iTunes Server
Packages
Mail Station
SqueezeCenter
Webalizer
UPnP Multimedia Service Support
Sony PS3, Microsoft Xbox360 (See All Supported DMA)
Audio Format: AAC, FLAC, M4A, MP3, Ogg Vorbis, WAV, WMA, WMA VBR, WMA PRO, WMA Lossless
Video Format: ASF, AVI, DAT, DivX, MP4, MPEG1, MPEG2, MPEG4, VOB, WMV, XviD
Image Format: BMP, JPG (jpe, jpeg), GIF, ICO, PNG, PSD, TIF (tiff), UFO
Playlist Format: WPL, M3U
iTunes Server Support
Audio Format: MP3, M4A, M4P, WAV4, AIF4
Playlist Format: M3U, WPL
Audio Station Support
USB Mode: (Audio) AAC, FLAC, M4A, MP3, Ogg Vorbis, WMA, WMA VBR (Playlist) M3U, WPL (Internet Radio) SHOUTcast, Radioio
Streaming Mode: (Audio) MP3 (Playlist) M3U, WPL
Photo Station 3 Support
Video Format: ASF, AVI, MPEG1, MPEG4, WMV, XviD, DivX, FLV, DAT5, MP45, MPEG25, RM5, RMVB5, VOB5
Image Format: BMP, JPG (jpe, jpeg), GIF
Management
AJAX-based Management UI
Sub-folder Privileges Setting
User Home
Applications privileges Setting
BitTorrent Port Range Setup
BitTorrent DHT Support
CIFS Recycle Bin
Download Station Bandwidth control
Download Station Port Range Setup
Editable HTTP Error Page
Email Alert Message
Email Notification for New User
Package Management
External HDD Hibernation (eSATA, USB)
Scheduled Power On/Off
Firmware Upgrade
FTP passive port range
Hide-able Shared Folder
Internal HDD Hibernation
Removable Default Shared Folder
System Temperature
Ez-Internet
PPPoE
UPS Management (Over USB 2.0)
User Quota
Web-based Download Station 2 |
Backup Solutions
Network Backup
Local Backup
Desktop Backup (using Synology Data Replicator 3)
3rd-Party Backup Support
Supported Clients
Windows 2000 onward
Mac OS X 10.3 onward
Linux
Printer Support6
Max Printer #: 2
Supported Protocols: LPR, CIFS, AppleTalk
Languages
English, German, French, Italian, Spanish, Danish, Norwegian, Swedish, Dutch, Russian, Korean, Polish, Traditional Chinese, Simplified Chinese, Portuguese (Brazil), Portuguese (European), Turkish, and
Hungarian
Environment
RoHS Compliant
Package Content
DS209+II Main Unit
Installation CD
Welcome Note
Assembling Kit
AC Power Adapter
AC Power Cord
2M RJ-45 LAN Cable
SATA Hard Drive Power Cable X2
SATA Hard Drive Data Cable X2
___
1. Hard drive not included.
2. FAN only. Measured at 2300~6200RPM, varied among models. More details about dB(A) value, check
http://www.quietnoise.com/facts.htm
3. Measured with 1 Seagate 750GB ST3750640NS hard drive. The figures could vary on different environments.
4. The music can be streamed, but the metadata (ex:title, album) may not be indexed on the iTunes.
5. User can click and download the file, but not play it in Photo Station as compressed Flash video.
6. For Mac users, DS109+ supports PostScript USB printers only.
7. 1 free license to install 1 IP camera. Additional licenses can be purchased to expand the license quota.
|
