Order Code: CM-6902NV
Manf.Code: NV-692A-KWN5
Introduction
CM 690 II Advanced NVIDIA Certified Edition (USB 3.0 version) comes with a NVIDIA logo side panel, clean looking external and internal accents. It makes it possible to take advantage of excellent airflow and water cooling options to vastly reduce temperatures on system components. The CPU mounting hole size has been enlarged to make installing CPU heatsink even more convenient, and the rubber grommets have been redesigned for improved cable management. Additionally, the CM 690 II Advanced NVIDIA Edition (USB 3.0) is equipped with two USB 3.0 internal connectors for faster data transfer.
| Features: | |
|
|
General
| Part Number | NV-692A |
| Model Number | NV-692A |
| Case Form Factor | Mid Tower |
| Dimensions (W, H, D) | Main Unit: 214.5 x 511.8 x 528.8 mm / 8.4 x 20 x 20.8 inches
|
| Front Panel Material | Steel (Plastic Bezel) |
| Side Panel Material | Steel (Plastic Bezel) |
| External Colour | Black |
| Internal Colour | Black |
| Weight | 9.19 kg / 20.26 lbs without Packaging
11.19 kg / 24.67 lbs with Packaging |
| 5.25" External | 4 |
| 3.5" External | 0 |
| 3.5" Internal | 6 (4 x Removable) |
| Expansion Slots | 7+1 |
| Full / E-ATX / Extended ATX | No |
| Standard ATX | Yes |
| Micro ATX | Yes |
| Mini ATX | Yes |
| Installed Fans | Front: 140 x 25 mm Green LED fan x 1 / 1200 RPM / 19 dBA
Rear: 120 mm fan x 1 / 1200 RPM / 17 dBA Top: 140 x 25 mm fan x 1 / 1200 RPM / 19 dBA (supports 120 / 140 mm fan x 2) Bottom: 120 mm fan x 2 (optional) HDD cage: 120 mm fan x 1 (optional) VGA holder: 80 x 15 mm fan x 1 (optional) |
| Connectivity |
USB 3.0 x 2
USB 2.0 x 2 eSATA x 1 MIC x 1 Audio x 1 (supports HD / AC97 audio) |
