Core i7 / i5 / i3 Support, ATX, DDR3 (max 32GB), PCIe 3.0, 4 x USB3, 14 x USB2, 4 x SATA 6Gb/s, 4 x SATA 3Gb/s, 1 x eSATA, RAID, HDMI, DVI, SPDIF
Sorry, this product is no longer available to purchase.
Please view our whole range of B Stock Motherboards here
LGA1155 Intel Second Generation Core i7/Core i5/Core i3 Processors Ready
This motherboard supports the latest Intel second generation Core i7/Core i5/Core i3 processors in the LGA1155 package, with memory and PCI Express controllers integrated to support 2-channel (4 DIMM) DDR3 memory and 16 PCI Express 2.0 lanes. This provides great graphics performance. Intel second generation Core i7/Core i5/Core i3 processors are among the most powerful and energy efficient CPUs in the world. |
|
Intel Z68 Express Chipset The Intel Z68 Express Chipset is a single-chipset design to support socket 1155 Intel second generation Core i7/Core i5/Core i3 processors. It provides improved performance by utilizing serial point-to-point links, allowing increased bandwidth and stability. Additionally, Z68 chipset provides 2 SATA 6Gb/s and 4 SATA 3Gb/s ports for faster data retrieval at double the bandwidth of current bus systems. Moreover, Intel Z68 Express Chipset also supports iGPU function, letting users enjoy the latest Intel integrated graphic performance. |
|
PCI Express 3.0 PCI Express 3.0 (PCIe 3.0) is the latest PCI Express bus standard with improved encoding schemes that provide twice the performance of current PCIe 2.0. Total bandwidth for a x16 link reaches a maximum of 32GB/s, double the 16GB/s of PCIe 2.0 (in x16 mode). As such, PCIe 3.0 provides users unprecedented data speeds, combined with the convenience and seamless transition offered by complete backward compatibility with PCIe 1.0 and PCIe 2.0 devices. PCIe 3.0 will become a must-have feature for users who wish to improve and optimize graphic performance, as well as have the latest technology available to them. |
|
LucidLogix Virtu Perfect Fit for Graphics and Multimedia. LucidLogix Virtu is designed for the Intel Sandy Bridge platform's powerful integrated graphics. Its GPU virtualization dynamically assigns tasks to the best available graphics resources based on power, performance and system load on Windows 7 based PCs. It allows users to fully utilize the unique capabilities of advanced Sandy Bridge multimedia features alongside the high end 3D rendering performance provided by installed graphics cards. When no discrete graphics are needed, the graphics card is put in idle mode to lower utilization, heat, fan speed and power draw down to near zero, making the system more environmentally-friendly. For users with diverse needs, LucidLogix Virtu GPU virtualization provides great flexibility and efficiency. |
|
HDMI Support Enjoy Full HD 1080p Multimedia Home-Theater Entertainment. High-Definition Multimedia Interface (HDMI) is a set of digital video standards that delivers multi-channel audio and uncompressed digital video for full HD 1080p visuals through through a single cable. Supporting HDCP copy protection such as Blu-ray Discs, HDMI provides you with the highest-quality home theater experience. |
|
Quad-GPU SLI and Quad-GPU CrossFireX Support! Flexible Multi-GPU solutions, Your Weapon of Choice! P8Z68-V PRO brings you the multi-GPU choice of either SLI or CrossFireX. The motherboard features the most powerful Intel Z68 platform to optimize PCIe allocation in multiple GPU configurations. Expect a brand-new gaming style you’ve never experienced before! |
Dual-Channel DDR3 2200(O.C.)/2133(O.C.)/1866(O.C.)/1600/1333/1066 MHz support The motherboard supports DDR3 memory that features data transfer rates of DDR3 2200(O.C.)/2133(O.C.)/1866(O.C.)/1600/1333/1066 MHz to meet the higher bandwidth requirements of the latest 3D graphics, multimedia and Internet applications. The dual-channel DDR3 architecture enlarges the bandwidth of your system memory to boost system performance. |
|
MemOK! Any Memory is A-OK! MemOK! quickly ensures memory boot compatibility. This remarkable memory rescue tool requires a mere push of a button to patch memory issues. MemOK! determines failsafe settings and dramatically improves your system boot success. Get your system up and running in no time! |
Auto Tuning Auto Tuning is an intelligent tool that automates overclocking to achieve a total system level up. This tool also provides stability testing. Even O.C. beginners can achieve extreme yet stable overclocking results with Auto Tuning! |
|
TurboV Accessible Performance on Demand. This intutive performance-improvement tool allows users to adjust the system performance paramaters with just a few clicks through its user-friendly interface. ASUS TurboV also allows users to save several profile settings to suit system performance scenarios as well. |
|
GPU Boost Go to the Limit with iGPU Level Up! GPU Boost accelerates the integrated GPU for extreme graphics performance. The user-friendly interface facilitates flexible frequency adjustments. It easily delivers stable system-level upgrades for every use. |
Extra SATA 6Gb/s Support Extra Ports, Extra Speed and Accessibility. The Intel Z68 Express chipset natively supports the next-generation Serial ATA (SATA) interface, delivering up to 6Gb/s data transfers. ASUS provides extra SATA 6Gb/s ports with enhanced scalability, faster data retrieval and double the bandwidth of current bus systems. |
|
Complete USB 3.0 Integration Double USB Access, Double Convenience. ASUS facilitates strategic USB 3.0 accessibility for both the front and rear panels - 4 USB 3.0 ports in total. Experience the latest plug & play connectivity at speeds up to 10 times faster than USB 2.0. The P8Z68-V PRO affords greater convenience with high speed connectivity. |
Dual Intelligent Processors 2 with DIGI+ VRM Digital Power Design: The New Standard. ASUS’ new generation Dual Intelligent Processors 2 with DIGI+ VRM launch motherboard power control into a whole new digital era. The 12+2 digital architecture provides the highest power efficiency, generating less heat to enhance longer component lifespan and ensure minimal power loss. With ASUS DIGI+ VRM, users can easily adjust power phase performance, enabling new PWM voltage and frequency modulation controls. Digital 12+2 power phase design also expands the modulation spectrum for improved stability and lower VRM switching noise by dynamically detecting system load, empowering users with superior flexibility and perfect precision to ensure optimized performance, extreme system stability, and greater power efficiency. |
|
ASUS TPU The Ultimate Turbo Processor. Unleash your performance with ASUS' simple onboard switch or AI Suite II utility. The TPU chip offers precise voltage control and advanced monitoring through Auto Tuning , GPU Boost and TurboV functions. Auto Tuning offers a user friendly way to automatically optimize the system for fast, yet stable clock speeds, while TurboV enables unlimited freedom to adjust CPU frequencies and ratios for optimized performance in diverse situations. |
|
ASUS EPU Energy Efficiency All Around. Tap into the world's first real-time PC power saving chip through a simple onboard switch or AI Suite II utility. Get total system-wide energy optimization by automatically detecting current PC loadings and intelligently moderating power consumption. This also reduces fan noise and extends component longevity! |
DIGI+ VRM Herald the Arrival of a New Digital Power Design Era. VRM, or voltage regulator modules, are considered among the most essential motherboard design components. They supply the voltage demanded by the CPU, and a good VRM must intelligently detect actual CPU power draw to provide precise power accordingly. ASUS DIGI+ VRM is an innovative, industry-leading technology that fully integrates Intel VRD12 specifications on a native level, greatly enhancing power to go far beyond the limits of analog designs. Unlike previous VRD versions, Intel VRD12 uses digital signals (SVID). To ensure perfect power delivery, ASUS specially designed DIGI+ VRM to sync completely with this new technology. ASUS DIGI+ VRM delivers intelligent power management to balance loadings for each power phase by detecting VRM temperatures to ensure longer component lifespan and better cooling. |
ASUS Fanless Design - Heat-sink solution The streamline-shaped heatsink features 0-dB thermal solution that offers users a noiseless PC environment. Not only the beautifully curved fins upgrade the visual enjoyment for motherboard users, but also the special Streamline Airflow Guiding design lowers the temperature of the north bridge chipset through high efficient heat-exchange. Combined with usability and aesthetics, the ASUS streamline-shaped heat-sink will give users an extremely silent and cooling experience with the elegant appearance! |
|
Fan Xpert Active Quiet & Cool. ASUS Fan Xpert intelligently allows users to adjust both the CPU and chassis fan speed according to different ambient temperature, which is caused by different climate conditions in different geographic regions and system loading. Built-in variety of useful profiles offer flexible controls of fan speed to achieve a quiet and cool environment. |
DTS DTS Surround Sensation UltraPC delivers exceptional 5.1 surround experience through the most common PC audio setups - your existing stereo speakers or headphones. In addition to virtual surround, “Bass enhancement” provides stronger low frequency bass sound, and “Voice clarification” provides clear human dialogue even with loud background sound. With these technologies, you may experience a better home-theater audio with ease. |
|
S/PDIF-out on Back I/O Port This motherboard provides convenient connectivity to external home theater audio systems via optical S/PDIF-out (SONY-PHILIPS Digital Interface) jacks. It allows to transfer digital audio without converting to analog format and keeps the best signal quality. |
Intel Smart Response Technology Faster Access, Bigger Storage Intel Smart Response Technology boosts overall system performance. It uses an installed fast SSD (min 18.6GB available) as a cache for frequently accessed operations, speeding up hard drive/main memory interaction. Key benefits are expedited hard drive speeds, reduced load and wait times and maximized storage utilization. Power consumption also goes down by reducing unnecessary hard drive spin, an important part of Green ASUS eco-friendly computing. |
|
BT GO! Diverse BT Enjoyment, New Technology Lifestyle. Onboard Bluetooth wireless design enables smart connectivity to Bluetooth devices with no additional adapter. ASUS BT GO! comes with 7 special functions that offer a significant breakthrough in Bluetooth evolution, including Folder Sync, BT Transfer, BT Turbo Remote, BT-to-Net, Music Player, Shot and Send, and Personal Manager. All are accessible through the exclusive, user-friendly ASUS interface. |
|
AI Suite II One-stop Access to Innovative ASUS Features. With its user-friendly interface, ASUS AI Suite II consolidates all the exclusive ASUS features into one simple to use software package. It allows users to supervise overclocking, energy management, fan speed control, voltage and sensor readings, and even interact with mobile devices via Bluetooth. This all-in-one software offers diverse and ease to use functions, with no need to switch back and forth between different utilities. |
|
UEFI BIOS (EZ Mode) Flexible & Easy BIOS Interface. Exclusive to ASUS motherboards, its UEFI (Unified Extensible Firmware Interface) is the first ever mouse-controlled graphical BIOS interface designed with dual selectable modes. It delivers a user-friendly interface that goes beyond traditional keyboard-only BIOS controls to enable more flexible and convenient input with quick scrolling. Users can easily navigate the UEFI BIOS with the smoothness of their operating system. Quick and simple overclocking and setup sharing is facilitated by the F12 hotkey BIOS snapshot feature. The exclusive EZ Mode displays frequently-accessed setup info, while the Advanced Mode is for experienced performance enthusiasts that demand far more intricate system control, including detailed DRAM information. |
|
ASUS Q-Design DIY quickly, DIY easily! ASUS Q-Design enhances your DIY experience. All of Q-LED, Q-Slot and Q-DIMM design speed up and simplify the DIY process! |
|
Intel LAN Support P8Z68-V PRO features Intel Gigabit LAN which complies with 802.3az Energy Efficient Ethernet (EEE) standard and reduces power consumption during normal operation and enhances faster transfer speed through dual interconnection between the Integrated LAN controller and Physical Layer (PHY). |
|
GreenASUS The motherboard is European Union´s Energy-related Products (ErP) ready, and ErP requires products to meet certain energy efficiency requirements in regards to energy consumptions. This is in line with ASUS vision of creating environment-friendly and energy-efficient products through product design and innovation to reduce carbon footprint of the product and thus mitigate environmental impacts. |
Part Number | P8Z68-V Pro/Gen3 |
Model Number | P8Z68-V Pro/Gen3 |
Form Factor | ATX |
Width | 30.5cm |
Depth | 24.4m |
Compatible Processors | Intel Core i7 Intel Core i5 Intel Core i3 |
Socket Type | LGA 1155 |
Chipset Manufacturer | Intel |
Chipset Type | Z68 |
RAM Installed / Max Capacity | 0 MB / 32 GB Max |
RAM Slots | 4 x DDR3 DIMM |
Supported RAM Technology | Dual Channel DDR3 SDRAM |
Supported RAM Speeds | DDR3 2200(O.C.)/2133(O.C.)/1866(O.C.)/1600/1333/1066 |
Expansion Slots Total (Free) | 2 x PCIe 3.0 x16 (single at x16 or dual at x8/x8)
1 x PCIe 2.0 x16 (running at x4) 2 x PCIe 2.0 x1 2 x PCI |
Video Controller | Supports Intel HD Video |
Multi-GPU Support | Supports AMD Quad-GPU CrossfireX Supports NVIDIA Quad-GPU SLI |
Ports Present & Quantity | 1 x Bluetooth module(s)
1 x DVI 1 x D-Sub 1 x HDMI 1 x eSATA 3Gb/s 1 x LAN (RJ45) port(s) 2 x USB 3.0 6 x USB 2.0 1 x Optical S/PDIF out 6 x Audio Jack(s) |
Ports Present & Quantity | 1 x USB 3.0 connectors supports additional 2 USB 3.0 ports
3 x USB 2.0 connectors supports additional 6 USB 2.0 ports 4 x SATA 6Gb/s connectors 4 x SATA 3Gb/s connectors 2 x IEEE 1394a connectors 2 x CPU Fan connectors 2 x Chassis Fan connectors 2 x Power Fan connectors 1 x S/PDIF out Header 1 x 24-pin EATX Power connector 1 x 8-pin ATX 12V Power connector 1 x Front panel audio connector(s) (AAFP) 1 x System panel(Q-Connector) 1 x MemOK! button 1 x TPU switch 1 x EPU switch |
Intel Z68 Express Chipset | 2 x SATA 6Gb/s 4 x SATA 3Gb/s RAID 0,1,5,10 Support Intel Smart Response Technology Support |
Marvell PCIe SATA Controller | 2 x SATA 6Gb/s |
JMicron JMB362 SATA controller | 1 x eSATA 3.0 Gb/s ports |
Controller | Intel 82579 Gigabit LAN |
Lan Speed | 10/100/1000 |
Ports | 1 x LAN(RJ45) port |
Controller/Codec/Information | Realtek ALC892 8-Channel High Definition Audio CODEC
Absolute Pitch 192khz/24bit True BD Lossless Sound BD Audio Layer Content Protection DTS Surround Sensation UltraPC Supports Jack-Detection, Multi-streaming, Front Panel Jack-Retasking Optical S/PDIF out ports at back I/O |
Feature List | ASUS Dual Intelligent Processors 2 with DIGI+ VRM
ASUS Digital Power Design ASUS DIGI+ VRM Utility ASUS EPU ASUS TPU ASUS Auto Tuning ASUS TurboV ASUS GPU Boost ASUS TPU switch ASUS BT GO! (Bluetooth) ASUS BT Turbo Remote ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface ASUSMemOK! ASUS AI Suite II ASUS AI Charger+ ASUS Anti Surge ASUS Disk Unlocker ASUS Quiet Thermal Solution ASUS Fanless Design: Heat-sink solution ASUS Fan Xpert ASUS EZ DIY ASUS Q-Shield ASUS Q-Connector ASUS O.C. Tuner ASUS CrashFree BIOS 3 ASUS EZ Flash 2 ASUS Q-Design ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED) ASUS Q-Slot ASUS Q-DIMM |
