Product Overview

Experience game-changing performance with the GeForce GTX 670 powered by a powerful new GeForce architecture that redefines smooth, seamless and lifelike gaming. The GeForce GTX 670 raises the performance bar with new NVIDIA GPU Boost technology that maximizes clock speeds on the fly for maximum performance in every gaming scenario. New NVIDIA Adaptive Vertical Sync technology adapts the monitor’s vertical-sync dynamically to current frame rates for maximum gaming smoothness and playability with the GeForce GTX 670. Take your gaming experience to the next level with NVIDIA Surround technology for an unmatched immersive gaming experience with a single GeForce GTX 670 graphics card and triple displays.

ASUS Exclusive Features

	DIGI+ VRM with 10-phase Super Alloy Power The new and exclusive Super Alloy Power technology on ASUS graphics cards uses a special alloy formula which is highly-magnetic, heat-resistant and anti-corrosive. It delivers a more stable and quieter operation compared to the reference design – a welcome bonus sought after by performance seekers. During overclocking, the Super Hybrid Engine acts as an intelligent controller to switch between high and low intensity power profiles in real time for 15% performance boost. Super Alloy Capacitor increases the card’s lifespan to 150,000 hours which is 2.5 times longer than traditional capacitors. Super Alloy components are reinforced with special alloy formula and manufactured under high temperature and pressure to deliver stable and noise-free operation.
	GPU Tweak Overclocking is made real-time and intuitive with ASUS GPU Tweak utility. It not only allows you to optimize clock speeds, voltage and fan speeds on up to four graphics cards independently or simultaneously, you can also select between GPU Tweak’s Standard or Advanced modes depending on your level of experience. For gamers out there, GPU Tweak enables instantaneous in-game video recording up to 720p resolution so you can share clips with the community easily.
	DirectCU II Cooling Technology If the GPU is the heart of a graphics card, then the cooling device would be its lungs. Without it, the graphics card would not be able to "breath" smoothly, causing it to break down or even cause the entire system to fail. For ultimate cooling, ASUS DirectCU thermal technology developed the ideal heat banishing copper in exclusively designed heat pipes for direct and fast heat dissipation. Thick copper heatpipes are accurately positioned in direct contact with the GPU surface so heat is transported and dissipated efficiently to the heatsink - achieving a 20% cooler performance than reference. Since heat is carried away faster, fans can spin at a lower speed thus resulting in quieter performance than reference.

NVIDIA Features

	NVIDIA Kepler GPU Architecture NVIDIA's Kepler GPU architecture has been designed from the ground up not just for maximum performance in the latest DirectX 11 games, but optimal performance per watt. The new SMX streaming multiprocessor is twice as efficient as the prior generation and the new geometry engine draws triangles twice as fast. The result is world class performance and the highest image quality in an elegant and power efficient graphics card.
	NVIDIA GPU Boost Technology Up until now, GPUs have operated at a fixed clock speed when playing 3D games, even if they have the potential to run faster. GPU Boost intelligently monitors graphics work load and increases the clock speed whenever possible. The result is that the GPU always performs at its peak and you get the highest framerate possible.
	NVIDIA Adaptive V-Sync Technology Nothing is more distracting than framerate stuttering and screen tearing. The first tends to occur when framerates are low, the second when framerates are high. Adaptive V-Sync is a smarter way to render frames. At high framerates, V-sync is enabled to eliminate tearing, at low frame rates, it's disabled to minimize stuttering. It gets rid of distractions so you can get on with gaming.
	NVIDIA PhysX Technology PhysX is designed specifically for hardware acceleration by powerful processors with hundreds of cores. Combined with the tremendous parallel processing capability of the GPU, PhysX will provide an exponential increase in physics processing power and will take gaming to a new level delivering rich, immersive physical gaming environments.
	NVIDIA CUDA Technology NVIDIA CUDA technology is the world’s only C language environment that enables programmers and developers to write software to solve complex computational problems in a fraction of the time by tapping into the many-core parallel processing power of GPUs. With millions of CUDA-capable GPUs already deployed, thousands of software programmers are already using the free CUDA software tools to accelerate applications—from video and audio encoding to oil and gas exploration, product design, medical imaging, and scientific research.
	NVIDIA Surround with up to 4 Monitors Nothing is as breathtaking as playing your favorite games across three monitors. At 5760 x 1080, the expanded field of view fully engages human peripheral vision and provides for the most immersive experience in racing and flight simulators. Add in a fourth display to keep tabs on chat, email or web while you are gaming.
	NVIDIA 3D Vision NVIDIA 3D Vision brings a fully immersive, stereoscopic 3D experience to the PC. A combination of high-tech wireless glasses and advanced software, 3D Vision transforms hundreds of PC games into full stereoscopic 3D. Get up to 2x monitor and keyboard brightness with NVIDIA 3D LightBoost technology. In addition, you can enjoy 3D movies and 3D digital photographs from 3DVisionLive.com in eye popping, crystal-clear quality.
	NVIDIA SLI Technology Used by the most demanding gamers worldwide, SLI lets you link up to three GeForce GTX 680s together for astounding performance. And with NVIDIA’s track record for fast and frequent software updates, you’ll not only get the best performance in existing games, but future games too.

General Specifications

Bus Interface	PCI Express 3.0 x16
Output Interface	1 x DVI-I 1 x DVI-D 1 x HDMI 1 x DisplayPort

Expansion / Connectivity

Compatible Slots	1 x PCI Express x16
Width	Dual Slot

GPU Specification

Core Clock	915 MHz Core Clock
Core Boost Clock	980 MHz Core Clock
CUDA Cores	1344

Memory Specification

Memory Type	256 bit GDDR5
Memory Size	2048 MB
Memory Effective Size	6008 Mhz

Display Specification

Multi-Monitor Support	Up to 4 displays
Max Digital Resolution	2560x1600
Max Analogue Resolution	2048x1536

Thermal Specification

Max GPU Temp	98C
Max Power Usage	175W
Minimum PSU Requirement	500W
Required Power Connectors	2 x 6-pin

Supported Technologies

Technologies

DirectX 11 Support PCIe 3.0 Support OpenGL 4.2 NVIDIA Kepler GPU Archtecture NVIDIA GPU Boost Technology NVIDIA Adaptive V-Sync Technology NVIDIA PhysX Technology NVIDIA CUDA Technology NVIDIA SLI Technology NVIDIA Surround Technology with 4 Monitor Support ASUS DirectCU II Cooling Technology

Manufacturer Warranty

Warranty

2 Years
