Product Overview

Offering 6 GB of GDDR5 graphics memory, 448 NVIDIA CUDA parallel processing cores and built on the innovative Fermi architecture, the NVIDIA Quadro 6000 by PNY is a true technological breakthrough delivering excellent performance across a broad range of design, animation and video applications. Using the Quadro 6000 graphics solution, your work flows — you can design, render and deliver higher quality projects in less time. The NVIDIA Quadro 6000 by PNY offers ECC memory and fast double precision to ensure the accuracy and fidelity of your work. Quadro is designed to run computationally intensive applications such as ray tracing, video processing and computational fluid dynamics; supports DirectX 11.0, OpenGL 4.1 and Shader Model 5.0 hardware acceleration, and drives a variety of display types including: CRTs, Digital Flat Panels, Projectors and HDTVs.

NVIDIA Features

	NVIDIA Quadro Scalable Geometry Engine Quadro Scalable Geometry Engine dramatically improves performance across a broad range of CAD, DCC and scientific applications, enabling your work to flow interactively with models and scenes that are an order of magnitude more complex than ever before.
	NVIDIA Parallel DataCache NVIDIA Parallel DataCache supports a true cache hierarchy combined with on-chip shared memory driving exceptional throughput, accelerating capabilities such as real-time ray tracing, physics processing and texture filtering.
	NVIDIA GPUDirect Whether you are exploring mountains of geological data, researching solutions to complex scientific problems, or racing to model fast-moving financial markets, you need a computing platform that delivers the highest throughput and lowest latency possible. GPU-accelerated clusters and workstations are widely recognized for providing the tremendous horsepower required to perform compute-intensive workloads, and your applications can achieve even faster results with NVIDIA GPUDirect
	NVIDIA GigaThread Engine NVIDIA GigaThread Engine provides up to 10x faster context switching compared to previous generation architectures, concurrent kernel execution, and improved thread block scheduling.
	NVIDIA Quadro Digital Video Pipeline The NVIDIA Quadro Digital Video Pipeline is the industry’s only GPU-accelerated solution for real-time acquisition, processing, and delivery of high-resolution video across standard and now 3D video broadcast environments.
	NVIDIA Quadro G-Sync Solution The Quadro G-Sync option card is an advanced solution that ensures frame synchronization between GPUs and provides a way to synchronize to an external source (also known as house sync). G-Sync allows advanced visualization systems to utilize many projectors or displays in unison delivering unprecedented levels of realism and betters ways to collaborate.
	NVIDIA CUDA Parallel Computing Architecture NVIDIA Quadro solutions leverage general purpose GPU computing using standard programming languages like C/C++ and Fortran, and emerging APIs such as OpenCL and Direct Compute. This broad adoption of CUDA is accelerating techniques like ray tracing, video and image processing, and computation fluid dynamics.
	NVIDIA Quadro GPU Tessellation Engine Quadro GPU Tessellation Engine delivers native OpenGL 4.0 and DirectX 11 capabilities, automatically generating finely detailed geometry for cinematic quality models and environments, without sacrificing performance.
	NVIDIA Dual Copy Engines Dual Copy Engines enables the highest rates of parallel data processing and concurrent throughput between the GPU and host, accelerating techniques such as ray tracing, color grading and physical simulation
	True High Performance Computing (HPC) True High Performance Computing (HPC) is enabled by a new architecture designed from the ground up for accuracy and speed. Quadro GPUs deliver the industry's fastest double precision floating point performance for applications such as medical imaging, finite element analysis and computational fluid dynamics.
	Mission-Critical Reliability Mission-Critical Reliability enabled by the world's first and only Error Correction Codes (ECC) memory for GPUs. Quadro solutions ensure data integrity and reliability by eliminating soft errors on register files, frame buffer and cache memory.
	NVIDIA SLI Multi-OS Technology NVIDIA Multi-OS technology enables a designer, artist, or engineer, to simultaneously run multiple, business-critical, graphics-intensive applications, from a fully virtualized system, eliminating the need for a multiple system work environment. An NVIDIA Multi-OS workstation, with dual Quadro GPUs and virtualization software, lets a user assign a dedicated Quadro GPU to both the host operating system and a range of optionally loaded guest operating systems, thus creating a fully virtualized workstation. Using an NVIDIA Multi-OS workstation, professionals can achieve improved productivity and resource management for faster results. In addition, IT managers increase the use of a single system’s resources, reducing IT deployments for overall lower cost of ownership.
	NVIDIA Maximus Technology NVIDIA Maximus technology combines the visualization and interactive design capability of NVIDIA Quadro GPUs and the high-performance computing power of NVIDIA Tesla GPUs in a single workstation. On an NVIDIA Maximus system the Tesla GPU companion processor performs the heavy lifting of photorealistic rendering or engineering simulation computation. This frees up CPU resources for the work they are best suited for while freeing the Quadro GPU to power rich, full-performance, interactive design. Designers and engineers can now perform simultaneous CAE, rendering, or structural/fluid analysis on the same system being used for design work. Plus, content-creation professionals can perform faster video editing, effects, and animation.
	NVIDIA 3D Vision Pro Stereoscopic Solution Advanced active shutter glasses deliver crystal-clear stereoscopic 3D visualization for the most immersive experience. RF technology enables a range of environments ranging from collaborative work spaces to theaters. 3D Vision Pro solution sold separately.

General Specifications

Bus Interface	PCI Express 2.0 x16
Output Interface	1 x DVI-I 2 x DisplayPort

Expansion / Connectivity

Compatible Slots	1 x PCI Express x16
Width	Dual Slot

GPU Specification

CUDA Cores	448
Teraflops (Single Precision)	1.03
Gigaflops (Double Precision)	515.2

Memory Specification

Memory Type	384 bit GDDR5
Memory Size	6 GB
Memory Effective Size	6008 Mhz

Display Specification

Multi-Monitor Support	Up to 2 displays
Max Digital Resolution	2560x1600
Max Analogue Resolution	N/A

Thermal Specification

Max Power Usage	204W
Minimum PSU Requirement	500W
Required Power Connectors	1 x 8-pin or 2 x 6-pin

Supported Technologies

Technologies

DirectX 11 Support Shader Model 5.0 OpenGL 4.1 NVIDIA CUDA Architecture NVIDIA SLI Mosaic Technology NVIDIA Maximus Technology NVIDIA NVIEW Display Management NVIDIA Quadro Panoramic NVIDIA SDI Option (Requires Additional SDI Card) NVIDIA Quadro G-Sync (Requires Additional G-Sync Card) NVIDIA Dual Copy Engines NVIDIA 3D Vision Pro NVIDIA SLI Technology NVIDIA SLI Multi-OS Technology FSAA (64x or 128x with SLI)

Manufacturer Warranty

Warranty

3 Years
