Introduction
Aiming for the high-end enthusiast market and for everyone seeking the best power supply out there, Antec's HCP-1200 unifies raw power with advanced PSU engineering to meet the demands of high performing PCs. A full-featured, 80 PLUS Gold-certified unit, the HCP-1200 is capable of outputting 99 percent of its rated power on its eight +12V rails, which contain high maximum loads to ensure graphics card compatibility.
Exclusive to the High Current series, the HCP-1200 boasts High Current heavy-gauge 16 AWG wiring that reduces conducted resistance, increasing efficiency and improving power delivery. In addition, a cool-running dual double-layer PCB and onboard DC to DC converters provide substantial voltage stability. To experience kilowatt-class power in an unmatched design, pick up Antec's HCP-1200. ion and mission-critical server applications.
Brand
Antec
General
Model Number
HCP-1200
AC Input
100 - 240 Vac
DC Output
+3.3V +5V +12V1 +12V2 +12V3 +12V4 +12V5 +12V6 +12V7 +12V8 -12V +5Vsb
Max Load
25A 25A 30A 30A 30A 30A 30A 30A 30A 30A 0.5A 4A
Power
Total Power
1200W
ATX 20+4-pin
x1
PCI-E 6+2pin
x8
PCI-E 8pin
x1
4+4 pin CPU
x1
SATA
x12
4 Pin Molex Peripheral
x9
Floppy
x1
Connectivity
Service & Support
5 Year Warranty
Manufacturer Warranty
Features
1200 watts of Continuous Power
80 PLUS™ Gold certified - up to 92% efficient
NVIDIA® SLI®-Ready certified, ATI CrossFire™ certified
High Current Hybrid Cable Management includes a 8-pin modular connector
Special heavy-gauge 16 AWG High Current cable at CPU reduces conducted resistance, increasing efficiency and improving power delivery
2 x 8-pin CPU connectors included for dual-CPU gaming and server applications
Gold-plated high-current terminals for optimal conductivity
Quiet 80 mm double ball bearing PWM cooling fan
Eight Fully-protected High Current +12V rails with high maximum loads assures graphics card compatibility
Up to 99% power available on +12V rails
DC-to-DC voltage regulator modules ensure stability
Highest quality Japanese brand capacitors ensure long-term reliability
Dual Double-layer PCB optimizes cooling efficiency and allows for heavy-duty components
ATX12V version 2.3 and EPS version 2.92 compliant
Full suite of industrial grade protection: Over current protection (OCP); Over voltage protection (OVP); Short circuit protection (SCP); Over power protection (OPP); Over thermal protection (OTP).
All cables braided and wrapped for better airflow and neatness
Universal Input - works on any 100V - 240V grid
Active PFC with PF: 0.99
Meets 2010 EUP requirement: 5Vsb < 1W
AQ5 Antec Quality 5-year limited warranty on parts and labor
Safety: cUL, TUV, CE, CB, FCC, C-TICK, CCC, BSMI, Gost-R
MTBF:100,000 hours
