Order Code: ASU-XON71
Manf.Code: 90-YAA060-1UAN00Z
Product Features
Audio Performance
| Output Signal-to-Noise Ratio | 116 dB for Front-out 112dB for other channels |
| Input Signal-to-Noise Ratio | 112dB |
| Output THD+N at 1kHz | 0.00056% (-105dB) for Front-out |
| Input THD+N at 1kHz | 0.0004% (-108dB) for Line-in |
| Frequency Response | <10Hz to 48KHz |
| Output/Input Full-Scale Voltage | 2 Vrms (5.65 Vp-p) |
| Audio Processor | ASUS AV100 High-Definition Sound Processor |
| 24-bit D-A Converter of Digital Sources | Cirrus-Logic CS4398*1 for Front-Out Cirrus-Logic CS4362A*1 for other 6 channels |
| 24-bit A-D Converter for Analog Inputs | Cirrus-Logic CS5361* 1 |
| Playback Sample Rate | 44.1K/48K/96K/192KHz @ 16/24bit |
| Recording Sample Rate | 44.1K/48K/96K/192KHz @ 16/24bit |
| S/PDIF Digital Output | 44.1K/48K/96K/192KHz @ 16/24bit, Dolby Digital, DTS |
| Analog Output Jack | 3.50mm mini jack *4 (Front/Side/Center-Subwoofer/Back) |
| Analog Input Jack | 3.50mm mini jack *1 (Shared by Line-In/Mic-In) |
| Other line-level analog input | Aux-In (4-pin header on the card) |
| Digital S/PDIF Output | High-bandwidth TOS-Link optical transmitter |
| Front Panel Header | Headphone / Stereo Speaker Out Microphone In |
| Operation System | Windows 7/Vista/XP(32/64bit)/MCE2005 |
| Featured Technologies | Dolby Digital Live
Dolby Headphone Dolby Virtual Speaker Dolby Pro-Logic IIx DS3D GX 2.0 VocalFX Acoustic Echo Cancellation (AEC) Smart Volume Normalizer Karaoke Functions FlexBass Xear 3D Virtual Speaker Shifter 10-band Equalier 27 Environment Effects DirectSound3D® GX 2.0 & 1.0 EAX 2.0&1.0 DirectSound® HW DirectSound SW A3D 1.0 OpenAL generic modes 128 3D sounds processing capability |
Why not Tell A Friend about this product, all you need to do is fill out their information below and click send.
Your Name
Your Email
Friends Name
Friends Email
Personal Message
We love having your feedback on all of your products, we do ask that you keep your reviews strictly about the product though. If you have any feedback about the service from the company please contact ourCustomer Servicesteam. Thank you.
Reviewed by TimAPPS
, Alverstoke.
2011-11-25
Asus really have a cracking product in their Xonar range. Dead easy to install with impressive support online from Asus. Perfect for Low profile or normal Home Theatre setups. The up change in sound quality and controllability from a motherboard sound system has to be experienced to be believed!
Reviewed by BW
, .
2010-09-12
A significant step up from my PCI Soundblaster Augidy ZS. Like lifting a veil on music and games. I thought my Z5300 speakers were to blame for the flat sound from my PC but it turns out that the majority of the problem was with the card.
Reviewed by CyberPunk
, .
2010-08-20
A lot of features for not much money, this card delivers! Easy to install with both full-size and low profile forms, it''s gratifying to come across PC accessories that just work!
Reviewed by Shed
, .
2010-06-10
Easy to install and set-up unlike my previous soundcard (a Creative one). Fantastic sound. Woth every penny.
