Billion BiPAC 7404VNOX 3G / VoIP / 802.11n ADSL2+ Wireless VPN Firewall Router

802.11 b/g/n, 300Mbps, 2.4Ghz, 4 x 10/100 RJ45 Ethernet Ports, 1 x RJ11 Port, 2 x VoIP RJ11 (FXS), 1 x VoIP RJ11 (FXO), 1 x USB (Supports 3G / HSDPA)

Order Code: BIL-74VNOX

Manf.Code: BIPAC 7404VNOX

Sorry, this product is no longer available to purchase.

Please view our whole range of ADSL Routers (BT Line) here

Product Features


  • Dual WAN interfaces for ADSL2+ and 3G connections
  • High speed Internet access with ADSL2 / 2+; backward compatible with ADSL
  • Auto fail-over feature to ensure an always-on connection
  • USB 2.0 port for plugging a 3G / HSDPA modem as backup (available separately)
  • Make phone calls via the Internet as well as PSTN Fixed-line
  • Voice over IP compliant with SIP standard
  • Two FXS ports for connecting to regular telephones (BiPAC 7404VGOX/VGPX)
  • One FXO port for voice calls via PSTN Fixed-line
  • Gateway - Least Cost Routing support (for retail package only)(BiPAC 7404VGOX/VGPX only)
  • 802.11n Wireless AP with WPA-PSK / WPA2-PSK support
  • Wi-Fi Protected Setup (WPS)
  • 16 IPSec VPN tunnels Support (BiPAC 7404VGOX only)
  • Secured VPN with powerful 3DES (BiPAC 7404VGOX only)
  • SOHO firewall security with DoS prevention and SPI
  • Quality of Service control
  • Supports IPTV Application
  • Ideal for: SOHO users, Office users or Event / Meeting organizers



    Product Overview


    Truly Cost Saving
    Making VoIP calls with toll-quality is extremely simple; just connect the router to your existing telephone sets. The BiPAC 7404VNOX series complies with the most popularly adopted VoIP industrial standard, SIP protocol, to ensure the interoperability with SIP devices and major VoIP Gateways. The Gateway feature called “Least Cost Routing” offers the choice of the most economical rate provided by different ITSP. One RJ-11 FXO port is integrated to transmit inbound and outbound calls through PSTN Fixed-line, so that users may still be able to receive phone calls through PSTN, while enjoying VoIP service at the same time. In addition, outgoing calls will be automatically redirected to PSTN when the Internet or VoIP service is not available. The router also supports a wider range of telephony features, such as call waiting, silence suppression, line echo cancellation, caller ID, etc.

    3G Mobility and Always-On Connection
    With the BiPAC 7404VNOX series you can connect a 3G / HSDPA USB modem to its built-in USB port, enabling you to use a 3G / HSDPA, UMTS, EDGE, GPRS, or GSM Internet connection, which makes downstream rates of up to 14.4 Mbps possible. With the increasing popularity of the 3G standard, communication via the BiPAC 7404VGX series is becoming more convenient and widely available - allowing you to watch movies, download music on the road, or access e-mail no matter where you may be. You can even share your Internet connection with others, no matter if you're in a meeting or speeding across the country on a train. The auto fail-over feature ensures maximum connectivity and minimum interruption by quickly and smoothly connecting to a 3G network in the event that your ADSL line fails. The BiPAC 7404VNOX series will then automatically reconnect to the ADSL connection when it's restored, reducing connection costs. These features are perfect for office situations where constant and uninterrupted connection is paramount and of upmost importance.

    Wireless Mobility and Protection
    With an integrated 802.11n Wireless Access Point, the router delivers up to 6 times speeds and 3 times wireless coverage of an 802.11b/g network device. It supports a data rate of up to 300 Mbps and is also compatible with 802.11b/g equipment. The Wireless Protected Access (WPA-PSK/WPA2-PSK) and Wired Equivalent Privacy (WEP) features enhance the level of transmission security and access control over Wireless LAN. The router also supports the Wi-Fi Protected Setup (WPS) standard, allowing users to establish a secure wireless network by simply pushing a button. If your network requires wider coverage, the built-in Wireless Distribution System (WDS) repeater function allows you to expand your wireless network without the need for any external wires or cables.

    Secure VPN Connections
    The BiPAC 7404VGOX supports embedded IPSec VPN (Virtual Private Network) protocols, allowing users to establish encrypted private connections of up to 16 simultaneous tunnels over the Internet. With a built-in DES / 3DES VPN accelerator, the router enhances IPSec VPN performance significantly - so you can access your corporate intranet and transmit sensitive data between branch offices and remote sites anytime; even when you are on the road, thus enhancing productivity greatly.

    • ADSL Compliance

  • Compliant with ADSL Standard
  • Full-rate ANSI T1.413 Issue 2
  • G.dmt (ITU G.992.1)
  • G.lite (ITU G.992.2)
  • G.hs (ITU G.994.1)
  • ADSL over ISDN / U-R2
  • Compliant with ADSL2 Standard
  • G.dmt.bis (ITU G.992.3)
  • ADSL2 Annex M (ITU G.992.3 Annex M) (BiPAC 7404VGOXA/VGPXA, and BiPAC 7401VGPXA only)
  • Compliant with ADSL2+ Standard
  • G.dmt.bis plus (ITU G.992.5)
  • ADSL2+ Annex M (ITU G.992.5 Annex M) (BiPAC 7404VGOXA/VGPXA, and BiPAC 7401VGPXA only)

    Network Protocols and Features
  • NAT, static routing and RIP-1 / 2
  • Universal Plug and Play (UPnP) Compliant
  • Dynamic Domain Name System (DDNS)
  • Virtual Server and DMZ
  • SNTP, DNS relay and IGMP Proxy
  • POP3 (email account checking)
  • IGMP snooping for video service

    Firewall
  • Built-in NAT firewall
  • Stateful Packet Inspection (SPI)
  • DoS attack prevention including IP Spoofing, Land Attack, Smurf Attack, Ping of Death, TCP SYN Flooding, etc.
  • Packet Filtering - port, source IP address, destination IP address, MAC address
  • URL Content Filtering - string or domain name detection in URL string

    Quality of Service Control
  • Supports the DiffServ approach
  • Traffic prioritization and bandwidth management based-on IP protocol, port number and address

    Wireless LAN
  • Compliant with IEEE 802.11n, 802.11g and 802.11b standards
  • 2.4 GHz – 2.484 GHz frequency range
  • Up to 300 Mbps wireless operation rate
  • Wi-Fi Protected Setup (WPS) for easy setup
  • 64/128 bits WEP supported for encryption
  • Wireless security with WPA-PSK/WPA2-PSK support
  • WDS repeater function support

    IPTV Applications
  • IGMP Snooping
  • Virtual LAN (VLAN)
  • Quality of Service (QoS)

    VoIP
  • Two RJ-11 FXS ports for connecting to regular telephones
  • One RJ-11 FXO port for PSTN Fixed-line
  • Compliant with SIP standard (RFC3261)
  • Supports G.711 A/µ law, and G.729 Audio Codec standards
  • Supports Telephony Features: call waiting, silence suppression, voice activity detection (VAD), comfort noise generation (CNG), G.168 line echo cancellation, caller ID (Bell 202,V23)
  • Voice over data, QoS control to ensure higher voice quality
  • Automatic fallback to PSTN Fixed-line when the Internet or VoIP service is not available
  • Gateway – Least Cost Routing support (for retail package only) ATM and PPP Protocols
  • ATM Adaptation Layer Type 5 (AAL5)
  • Multiple Protocol over AAL5 (RFC 2684, formerly RFC 1483)
  • Bridged or routed Ethernet encapsulation
  • VC and LLC based multiplexing
  • PPP over Ethernet (PPPoE)
  • PPP over ATM (RFC 2364)
  • Classical IP over ATM (RFC 1577)
  • MAC Encapsulated Routing (RFC 1483 MER)
  • OAM F4 / F5

    Virtual Private Network (VPN) (BiPAC 7404VNOX only)
  • 16 IPSec VPN Tunnels
  • 8 L2TP VPN Tunnels (Dial-in: 4, Dial-out: 4)
  • 8 PPTP VPN Tunnels (Dial-in: 4, Dial-out: 4)
  • Embedded IPSec, L2TP & PPTP client / server
  • IKE key management
  • DES, 3DES and AES encryption for IPSec
  • Embedded powerful 3DES accelerator
  • MPPE Encryption for PPTP
  • L2TP over IPSec
  • L2TP / PPTP / IPSec pass-through Management
  • Quick Installation Wizard and Auto-scan ADSL settings
  • Web-based GUI for remote and local management
  • Firmware upgrade and configuration data upload and download via web-based GUI
  • Embedded Telnet server for remote and local management
  • SNMP v3, MIB-I and MIB-II support
  • Supports DHCP server / client / relay
  • TR-069*1 supports remote management

    Physical Interface
  • WLAN: detachable antenna
  • DSL: ADSL port
  • Telephone:
  • 1-port FXO (For PSTN Fixed-line support)
  • 2-port FXS (BiPAC 7404VGOX/7404VGPX)
  • 1-port FXS (BiPAC 7401VGPX)
  • USB 2.0 supports 3G/HSDPA modem backup
  • Ethernet: 4-port 10/100M auto-crossover (MDI/MDI-X) Switch
  • Console: the Ethernet Port # 4 can be also connected to console
  • Factory default reset button
  • WPS push button
  • Power jack
  • Power switch

    Physical Specification
  • Dimensions: 9.04" x 6.10" x 1.46" (229.5mm x 155mm x 37mm)

    Power Requirement
  • Input: 15V DC, 1.6A

    Operating Environment
  • Operating temperature: 0 ~ 40 °C
  • Storage temperature: -20 ~ 70 °C
  • Operating Humidity: 20% ~ 95% non-condensing
