Billion BiPAC 7700N 300Mbps Wireless-N ADSL2+ Modem Router

802.11 b/g/n, 300Mbps, 2.4Ghz, 4 x 10/100 RJ45 Ports, 1 x RJ11 Port

Sorry, this product is no longer available to purchase.

Please view our whole range of ADSL Routers (BT Line) here

Spend between £100 and £600 to get your goods before you pay

More information

Product Features


  • Supports Multiple LAN segment for multiple network application
  • 4-port 10 / 100Mbps Ethernet switch integrated
  • High-speed Internet Access via ADSL2 / 2+; Backward compatible with ADSL
  • Built in 802.11n Wireless Access Point
  • WPA-PSK/ WPA2-PSK, Wi-Fi Protected Setup (WPS) and WEP support
  • Wireless speed up to 300Mbps
  • Quality of Service Control for traffic prioritization management
  • SOHO Firewall security with DoS Prevention and Packet Filtering
  • Universal Plug and Play (UPnP) compliance
  • Dynamic Domain Name System (DDNS)
  • Available Syslog
  • Supports IPTV Application

    Optimal Wireless speeds and coverage


    Utilizing the benefits of Wireless N technology, BiPAC 7700N performs faster file transfers and farther coverage enabling greater wireless signals across your home. If the network requires wider coverage, the built-in Wireless Distribution System (WDS) repeater function allows users to expand the wireless network without the need for any external wires or cables. Upgrading your home network to Wireless N provides an excellent solution for experiencing better wireless performance while sharing a broadband Internet connection with multiple computers over a secure wireless network.

    Quality Transmission Enhances Internet Experience


    Quality of Service (QoS) gives full control over outgoing data traffic. Priority can be assigned by the router to ensure that important transmissions like gaming packets, VoIP calls or IPTV / streaming content passes through the router at lightning speed, even when there is heavy Internet traffic. The VLAN support is also capable of establishing reliable high-speed transmissions for wide bandwidth applications such as IPTV, VOD, or online gaming without consuming bandwidth.

    High-speed Internet Access


    The BiPAC 7700N is compliant with worldwide ADSL standards, and supports download rates of up to 12 / 24Mbps using ADSL2 / 2+, 8Mbps using ADSL and an upload rate of up to 1Mbps. The integrated Annex M standard supports ADSL2 / 2+ for higher uploads by doubling the upload data rate. The 4-port Ethernet Switch incorporated into the BiPAC 7700N enables users to connect to multiple computers or wired-Ethernet devices easily and enjoy blistering LAN transmission for multimedia applications such as interactive gaming, IPTV video streaming and real-time audio.

    • Hardware Features

    Interface 4 x 10/100Mbps LAN Ports
    1 x RJ11 Port
    Button 1 x Power Button
    1 x WPS Button
    1 x WLAN On/Off Button
    Power Supply External Power Supply
    Dimensions(WxDxH) 150 x 110 x 22mm
    Antenna Type Fixed Omni-Directional
    Antenna Gain 2 x 2dBi

    ADSL Specification
    ADSL Standards Full-rate ANSI T1.413 Issue 2
    G.dmt (ITU G.992.1)
    G.lite (ITU G.992.2)
    G.hs (ITU G.994.1)
    ADSL2 Standards G.dmt.bis (ITU G.992.3)
    ADSL2 Annex M (ITU G.992.3 Annex M)
    ADSL2+ Standards G.dmt.bis plus (ITU G.992.5)
    ADSL2+ Annex M (ITU G.992.5 Annex M)

    Wireless Features
    Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
    Wireless Frequency 2.400-2.4835GHz
    Wireless Transfer Speed up to 300Mbps
    Wireless Security 64/128 bits WEP Supported for Encryption
    WPA-PSK/ WPA2-PSK Support
    WPS (Wi-Fi Protected Setup)

    Other Features
    Network Protocols Universal Plug and Play (UPnP) Compliant
    Dynamic Domain Name System (DDNS)
    Virtual Server and DMZ
    SNTP, DNS relay and IGMP proxy
    IGMP snooping for video service
    Management based-on IP protocol, port number and address
    Firewall Built-in NAT Firewall
    Stateful Packet Inspection (SPI)
    Prevents DoS attacks including Land Attack, Ping of Death, etc.
    Remote access control for web base access
    Packet Filtering - port, source IP address, destination IP address, MAC address
    URL Filtering
    Password protection for system management
    VPN pass-through
    Quality of Service Control Supports the DiffServ approach
    Traffic prioritization management based-on IP protocol, port number and address
    ATM and PPP Protocols ATM Adaptation Layer Type 5 (AAL5)
    Classical IP over ATM (IPoA) (RFC 2225 / RFC 1577)
    IP over Ethernet (RFC1483/RFC2684)
    VC and LLC based multiplexing
    PPP over Ethernet (PPPoE)
    PPP over ATM (RFC 2364)
    MAC Encapsulated Routing (RFC 1483 MER)
    OAM F4 / F5
    IPTV Applications Virtual LAN (VLAN)
    Quality of Service (QoS)
    IGMP Snooping & IGMP Proxy
    VLAN MUX support
    Management Web-based GUI for remote and local management
    Firmware upgrades and configuration data upload and download via web-based GUI
    Embedded Telnet server for remote and local management
    Available Syslog
    Supports DHCP server / client / relay
    TR-069*3 supports remote management
    SNMP v1/v2 supports remote and local management
