Customise your HyperServe SSDG-1U12
- Dual AMD EPYC™ 9005 series processors
- 12-Channel RDIMM/3DS RDIMM DDR5 per processor, 24 x DIMMs
- 1 x Management Port
- 12 x 2.5” Hot-swap Storage Bays, 2 x M.2 sockets (Gen3 x4 link, up to 22110)
- Up to 2 x PCIe Gen5 slots (FHHL) + 2 x OCP 3.0 Gen 5 slots (SFF)
- 1+1 Redundant 2000W 80 PLUS Titanium Power Supply
- 1U, 800mm Depth
Configure from £8120.32 inc VAT
or
| CPU Support | AMD EPYC™ 9005 Series Processors (Air cool with EVAC up to 400W) |
| Socket | 2 x Socket SP5 (LGA 6096P) |
| Memory | Total Slots:24 (12-channel per CPU, 1 DIMM per CPU) Capacity :Maximum up to 3072GB per socket Memory Type :DDR5 6400/5600 RDIMM/ 3DS RDIMM Memory Size :128GB, 96GB, 64GB, 32GB RDIMM 128GB, 96GB, 64GB, 32GB 3DS RDIMM |
| Expansion Slots | Total Slots: Up to 2 x PCIe Gen5 slots + 2 x OCP3.0 Gen5 slots 1 x PCIe Gen5 x16 (FHHL) 1 x PCIe Gen5 x16 (FHHL) 1 x OCP3.0 Gen5 x16 (SFF) 1 x OCP3.0 Gen5 x16 (SFF) |
| Disk Controller | SATA Controller:2 x DIMM.2 Gen3 x4 (22110, 2280, 2260) |
| SAS Controller:Optional kits: Broadcom HBA CARD 9500-16i Broadcom MegaRAID 9560-16i |
|
| Storage Bays | 12 x 2.5" Hot-Swap Drive Bays up to (12 x NVMe/SATA/SAS*) *RAID card is required to support SAS hard drives |
| Networking | 1 x Management Port |
| Graphics | Aspeed AST2600 64MB |
| I/O Ports | Rear: 2 x USB 3.2 Gen1 ports 1 x Management port 1 x Debug port 1 x Mini-DP port |
OS Support | Please find the latest OS support from http://www.asus.com/ |
| Management Solution | On-Board ASMB12-iKVM for KVM-over-IP ASUS Control Center Enterprise (Classic C)(Optional) |
| Regulatory Compliance | BSMI, CE, CB, C-Tick, FCC(Class A) |
| Dimensions | 821.7(L) x 483(W) x 43.2(H) mm |
| Form Factor | 1U |
| Weight | Net Weight: 13.81 kg Gross Weight: 16.71 Kg |
| Power Supply | 1+1 Redundant 2000W 80 PLUS Titanium/Platinum PSU Rating: 100-127V~/220-240V~, 12A/10A (x2), 50/60Hz |
| Environment | Operation temperature: 10? ~ 35? Non operation temperature: -40? ~ 60? Non operation humidity: 20% ~ 90% (Non condensing) |
Case
Processor
Default part
AMD EPYC Turin Dual Socket Processors
1
x
AMD EPYC Turin 9015, 8 Core 16 Threads, 3.6GHz, 64MB Cache, 125Watts.
1
x
AMD EPYC Turin 9115, 16 Core 32 Threads, 2.6GHz, 64MB Cache, 125Watts.
1
x
AMD EPYC Turin 9135, 16 Core 32 Threads, 3.65GHz, 64MB Cache, 200Watts.
1
x
AMD EPYC Turin 9175F, 16 Core 32 Threads, 4.2GHz, 512MB Cache, 320Watts.
1
x
AMD EPYC Turin 9255, 24 Core 48 Threads, 3.2GHz, 128MB Cache, 200Watts.
1
x
AMD EPYC Turin 9275F, 24 Core 48 Threads, 4.1GHz, 256MB Cache, 320Watts.
1
x
AMD EPYC Turin 9335, 32 Core 64 Threads, 3.0GHz, 128MB Cache, 210Watts.
1
x
AMD EPYC Turin 9355, 32 Core 64 Threads, 3.55GHz, 256MB Cache, 280Watts.
1
x
AMD EPYC Turin 9365, 36 Core 72 Threads, 3.4GHz, 192MB Cache, 300Watts.
1
x
AMD EPYC Turin 9375F, 32 Core 64 Threads, 3.8GHz, 256MB Cache, 320Watts.
1
x
AMD EPYC Turin 9455, 48 Core 96 Threads, 3.15GHz, 256MB Cache, 300Watts.
1
x
AMD EPYC Turin 9475F, 48 Core 96 Threads, 3.65GHz, 256MB Cache, 400Watts.
1
x
AMD EPYC Turin 9535, 64 Core 128 Threads, 2.4GHz, 256MB Cache, 300Watts.
1
x
AMD EPYC Turin 9555, 64 Core 128 Threads, 3.2GHz, 256MB Cache, 360Watts.
1
x
AMD EPYC Turin 9575F, 64 Core 128 Threads, 3.3GHz, 256MB Cache, 400Watts.
1
x
AMD EPYC Turin 9565, 72 Core 144 Threads, 3.15GHz, 384MB Cache, 400Watts.
1
x
AMD EPYC Turin 9645, 96 Core 192 Threads, 2.3GHz, 256MB Cache, 320Watts.
1
x
AMD EPYC Turin 9655, 96 Core 192 Threads, 2.6GHz, 384MB Cache, 400Watts.
1
x
AMD EPYC Turin 9745, 128 Core 256 Threads, 2.4GHz, 256MB Cache, 400Watts.
1
x
AMD EPYC Turin 9755, 128 Core 256 Threads, 2.7GHz, 512MB Cache, 500Watts.
1
x
AMD EPYC Turin 9825, 144 Core 288 Threads, 2.2GHz, 384MB Cache, 390Watts.
1
x
AMD EPYC Turin 9845, 160 Core 320 Threads, 2.1GHz, 320MB Cache, 390Watts.
1
x
AMD EPYC Turin 9965, 192 Core 384 Threads, 2.25GHz, 384MB Cache, 500Watts.
AMD EPYC Genoa Dual Socket Processors
1
x
AMD EPYC Genoa 9354, 32 Core 64 Threads, 3.25GHz, 256MB Cache, 280Watts.
1
x
AMD EPYC Genoa 9554, 64 Core 128 Threads, 3.10GHz, 256MB Cache, 360Watts.
1
x
AMD EPYC Genoa 9654, 96 Core 192 Threads, 2.40GHz, 384MB Cache, 360Watts.
1
x
AMD EPYC Genoa 9754, 128 Core 256 Threads,2.25GHz, 256MB Cache, 360Watts.
Memory
Default part
DDR5 5600Mhz RDIMM Memory
1
x
16GB DDR5 5600Mhz RDIMM Memory
1
x
32GB DDR5 5600Mhz RDIMM Memory
1
x
64GB DDR5 5600Mhz RDIMM Memory
1
x
96GB DDR5 5600Mhz RDIMM Memory
1
x
128GB DDR5 5600Mhz RDIMM Memory
Raid Controller
Default part
Graid SupremeRAID Cards
SupremeRAID™ Core - Graid Technology SupremeRAID V2 Software Module License with full features, supports 16 native NVMe drives with bundled Nvidia GPU
SupremeRAID™ Pro - Graid Technology SupremeRAID V2 Software Module License with full features, supports 32 native NVMe drives with bundled Nvidia GPU
SupremeRAID™ Ultra - Technology SupremeRAID V2 Software Module License with full features, supports 32 native NVMe drives with bundled Nvidia GPU
OCP 3.0
Default part
Intel OCP 3.0 Modules
Intel X710-T2L Dual Port 10GbE/5Gbe/2.5GbE/1GbE/100Mb RJ45, OCP 3.0
Intel X710-T4L Quad Port 10GbE/5GbE/2.5GbE/1GbE/100Mb RJ45, OCP 3.0
Intel X710-DA2 Dual Port 10/1GbE SFP+, OCP 3.0
Intel X710-DA4 Quad Port 10/1GbE SFP+, OCP 3.0
Intel E810-XXVDA2 Dual Port 25/10/1GbE SFP28, OCP 3.0
Intel E810-XXVDA4 Quad Port 25/10/1GbE SFP28, OCP 3.0
Intel E810-CQDA1 Single Port 100/50/25/10GbE QSFP28, OCP 3.0
Intel E810-CQDA2 Dual Port 100/50/25/10GbE QSFP28, OCP 3.0
M.2 Storage
Kingston DC2000B Series NVME M.2 SSD's
0
Kingston DC2000B 240GB M.2 (2280) NVMe Enterprise SSD (Heatsink)
0
Kingston DC2000B 480GB M.2 (2280) NVMe Enterprise SSD (Heatsink)
0
Kingston DC2000B 960GB M.2 (2280) NVMe Enterprise SSD (Heatsink)
Harddrives
Filter by:
Samsung PM9A3 2.5" U.2 NVME Data Centre
0
Samsung PM9A3 960GB 2.5" U.2 NVME PCIE-E 4.0 Datacentre SSD
0
Samsung PM9A3 1.92TB 2.5" U.2 NVME PCIE-E 4.0 Datacentre SSD
0
Samsung PM9A3 3.84TB 2.5" U.2 NVME PCIE-E 4.0 Datacentre SSD
0
Samsung PM9A3 7.68TB 2.5" U.2 NVME PCIE-E 4.0 Datacentre SSD
Micron 7500 MAX Enterprise U.3 NVMe - Mixed Use, 3 DWPD
0
Micron 7500 MAX 800GB U.3 2.5" NVMe SSD
0
Micron 7500 MAX 1.6TB U.3 2.5" NVMe SSD
0
Micron 7500 MAX 3.2TB U.3 2.5" NVMe SSD
0
Micron 7500 MAX 6.4TB U.3 2.5" NVMe SSD
0
Micron 7500 MAX 12.8TB U.3 2.5" NVMe SSD
Micron 7500 Pro Enterprise U.3 NVMe - Read Intensive, 1 DWPD
0
Micron 7500 PRO 960GB U.3 2.5" NVMe SSD
0
Micron 7500 PRO 1.9TB U.3 2.5" NVMe SSD
0
Micron 7500 PRO 3.84TB U.3 2.5" NVMe SSD
0
Micron 7500 PRO 7.68TB U.3 2.5" NVMe SSD
0
Micron 7500 PRO 15.3TB U.3 2.5" NVMe SSD
Micron 9400 MAX Enterprise U.3 NVMe - 3 DWPD
0
Micron 9400 MAX 6.4TB U.3 NVME SSD
0
Micron 9400 MAX 12.8TB U.3 NVME SSD
0
Micron 9400 MAX 25.6TB U.3 NVME SSD
Micron 9400 Pro Enterprise U.3 NVMe - 1 DWPD
0
Micron 9400 Pro 7.68TB U.3 NVME SSD
0
Micron 9400 Pro 15.36TB U.3 NVME SSD
0
Micron 9400 Pro 30.7TB U.3 NVME SSD
Power Supply
Networking
Default part
Intel 100GbE Adapters
Intel E810-CQDA1 Single Port 100GbE QSFP28 Ethernet Controller
Intel E810-CQDA1 Dual Port 100GbE QSFP28 Ethernet Controller
Intel 25/40GbE Adapters
Intel XXV710-DA2 Dual Port 25GbE SFP28 Ethernet Adapter
Intel XL710-QDA2 Dual Port 40GbE QSFP+ Ethernet Converged Adapter
Intel E810-XXVDA4 Quad Port 25GbE SFP28 Ethernet Adapter
Intel 10GbE Adapters
Intel X550-T2 Dual Port 10GbE RJ45 Ethernet Adapter
Intel X520-SR2 Dual Port 10GbE SFP+ Server Adapter
Intel X710-DA2 Dual Port 10GbE SFP+ Ethernet Adapter
Rail Kit
Operating System
Default part
Open Source Linux
Open Source Linux Installed and Setup as per Customer Instructions
Microsoft Windows Server 2025
Microsoft Windows Server 2025 Standard (16-core)
Microsoft Windows Server 2025 Standard (24-core)
Microsoft Windows Server 2025 Datacenter (16-core)
Microsoft Windows Server 2025 Datacenter (24-core)
Support Package
Default part
Proxmox Virtual Environment
Proxmox VE Community Subscription 1 CPU / year
Proxmox VE Community Subscription 2 CPUs / year
Proxmox VE Community Subscription 4 CPUs / year
Proxmox VE Basic Subscription 1 CPU/year
Proxmox VE Basic Subscription 2 CPUs/year
Proxmox VE Basic Subscription 4 CPUs/year
Proxmox VE Standard Subscription 1 CPU/year
Proxmox VE Standard Subscription 2 CPUs/year
Proxmox VE Standard Subscription 4 CPUs/year
Proxmox VE Premium Subscription 1 CPU/year
Proxmox VE Premium Subscription 2 CPUs/year
Proxmox VE Premium Subscription 4 CPUs/year
Standard build time 5 working days
