OS Support
The Gigabyte B350 Chipset Motherboards Support the following Operating Systems:
- Windows® 10 64-bit
M-ATX, DDR4, 2 x USB 3.1 Gen2, 2 USB 3.1 Gen1, 4 x USB 3.1, 6 x USB 2.0,1 x M.2, 2 x PCI-E 3.0 x16, 1 x PCI-E x1, Crossfire
Sorry, this product is no longer available to purchase.
Please view our whole range of Socket AM4 Ryzen (B350 Chipset) here
The Gigabyte B350 Chipset Motherboards Support the following Operating Systems:
Socket | AM4 socket for AMD Ryzen™/7th Generation A-series/Athlon™ Processors |
Architecture | 14nm CPU |
Chipset | AMD B350 Chipset |
Memory Slots | 4 DIMM / 64GB Max DDR4 |
Memory Support | DDR4 up to 3200MHz (OC) Un-buffered memory |
ECC | No |
Channels | Dual Channel Architecture |
Expansion Slots | 2 x PCIe 3.0 x16 slots 1 x PCIe x1 slot |
Integrated Graphics Processor | HDMI/DVI-D/D-SUB |
Multi-GPU | 2-Way Crossfire |
Sata | 6 x SATA 6Gb/s ports |
M.2/U.2 | 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4*/x2 SSD support) |
Ports Present & Quantity | 1 x PS/2 keyboard/mouse port 1 x D-Sub port 1 x DVI-D port 1 x HDMI port 4 x USB 3.1 Gen 1 ports 2 x USB 3.1 Gen 2 Type-A ports (red) 2 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks (Line In, Line Out, Mic In) |
Ports Present & Quantity | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x M.2 Socket 3 connector 6 x SATA 6Gb/s connectors 1 x CPU fan header 2 x system fan headers 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB 3.1 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header 2 x serial port headers 1 x parallel port header 1 x Clear CMOS jumper |
Unique Features | Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. @BIOS 3D OSD AutoGreen Ambient LED BIOS Setup Cloud Station Color Temperature EasyTune Fast Boot Game Boost ON/OFF Charge Smart Backup Smart Keyboard Smart TimeLock System Information Viewer USB Blocker V-Tuner Support for Q-Flash Support for Xpress Install |
Software | Norton® Internet Security (OEM version) cFosSpeed |
OS | Windows® 10 64-bit Support for Windows 7 64-bit * Please download the "Windows USB Installation Tool" from GIGABYTE's website and install it before installing Windows 7. |
Form Factor | M-ATX |
Dimensions | 24.4cm x 24.4cm |
