X670 AORUS ELITE AX, ATX, AM5, DDR5, 2 x PCIe 4.0/3.0 x16, 1 x PCIe 3.0 x16, 4 x M.2, 4 x SATA, 1 x 2.5 Gb LAN, Wi-Fi 6E, HDMI
£319.99 inc vat
£266.66 ex vatOr £13.82 for 24 months
with 10% deposit of £32.00
Order Code: GIG-X67AEX
Manf.Code: X670 AORUS ELITE AX
Get ready to usher in the new age of AM5 overclocking with AMD X670 motherboards and AMD Ryzen 7000 Series processors
With the fast pace of technology changes, GIGABYTE follows with the latest trends and provides customers with advanced features and the latest technologies. GIGABYTE motherboards come with an upgraded power solution, latest storage standards and outstanding connectivity to enable optimize performance for gaming needs.
To ensure maximum Turbo Boost and overclocking performance of AMD's new generation CPU, GIGABYTE AORUS series motherboards equip the best VRM design ever built with the highest quality components.
The first PCIe 5.0 x4 M.2 Slot supports the latest M.2 25110 form factor. Reinforced PCIe 5.0 M.2 connectors with metal shielding to provide higher strength.
GIGABYTE AM5 MB supports both AMD EXPO™ and Intel® XMP overclocking memory modules for maximal compatibility. MB will automatically detect both profiles format in SPD, users can choose to enable one of profiles from BIOS menu and easily reach overclocked memory performance.
GIGABYTE Motherboards Un-throttled performance is guaranteed by innovative and optimized thermal design to ensure the best CPU, Chipset, SSD stability and low temperatures under full load application and gaming performance.
With durability in mind, GIGABYTE provides a thermal solution for M.2 SSD devices. The M.2 Thermal Guard prevents throttling and bottlenecks from high speed M.2 SSDs as it helps to dissipate heat before it becomes an issue.
By adopting 2X copper on PCB inner layer, it lowers the components temperature at least 3% by turning the PCB into a super thin PCB size copper heatsink to dissipate the heat from the components effectively, due to it's high thermal conductivity and lower impedance.
Smart Fan 6 contains several unique cooling features that ensure the gaming PC maintains its performance while staying cool and quiet. Multiple fan headers can support PWM/DC fan and pump, and users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface.
GIGABYTE Motherboards enable the ultimate connection experience with blazing data-transfer speeds through the next generation network, storage, and WIFI connectivity.
The latest Wireless solution 802.11ax Wi-Fi 6E with new dedicated 6GHz band, enables gigabit wireless performance, provides smooth video streaming, better gaming experience, few dropped connections and speeds up to 2.4Gbps. Moreover, Bluetooth 5 provides 4X range over BT 4.2 and with faster transmission.
Adoption of 2.5G LAN provide up to 2.5GbE network connectivity, with at least 2 times faster transfer speeds compared to general 1GbE networking, perfectly designed for gamers with ultimate online gaming experience.
Featuring USB 3.2 Gen 2x2 design which is double the performance of the previous generation of USB 3.2 Gen 2. It works up to 20Gbps ultra-fast data transfer while connecting to USB 3.2 compliant peripherals. Through the USB Type-C® connector, users can enjoy the flexibility of reversible connection to access and store massive amounts of data rapidly.
AORUS motherboards use high-end audio capacitors. These high quality capacitors help deliver high resolution and high fidelity audio to provide the most realistic sound effects for gamers. AORUS motherboards feature an audio noise guard that essentially separates the board's sensitive analog audio components from potential noise pollution at the PCB level.
GIGABYTE motherboards bundle several useful and intuitive software to help users to control every aspect of motherboard and provide customizable lighting effect with outstanding aesthetics to fit your unique personality.
Now offering more LED customizations than ever, users can truly adapt their PC to represent their lifestyle. With full RGB support and a redesigned RGB Fusion 2.0 application, the user has complete control over the LEDs which surround the motherboard.
GIGABYTE CONTROL CENTER (GCC) is a unified software for all GIGABYTE supported products. It provides newly designed intuitive user interface to control all essential function.
A multi-function reset button that can be reconfigured to other function in BIOS for different user scenarios.
All new EASY MODE shows important hardware information in one page including CPU clock, Memory, Storage, Fan.
GIGABYTE Ultra Durable™ design provides product durability and high-quality manufacturing process. GIGABYTE motherboards use the best components and reinforce every slot to make each of them solid and durable.
With PCIe EZ-Latch you can unlock the latch of the PCIe slot easily when removing the graphics card in the PCIe slot.
With GIGABYTE Q-Flash Plus, you don't need to install the CPU, memory and graphics card nor enter the BIOS menu to flash the BIOS. Just download and save a new BIOS file (rename to gigabyte.bin) on the USB flash drive, then press the dedicated Q-Flash Plus button and you're good to go!
|CPU Support||Supports AMD Ryzen 7000 Series Desktop Processors|
|Chipset||AMD X670 Chipset|
|Memory Support||4 x DDR5 memory slots supporting up 128GB
Dual Channel Technology
Supports up to 5600Mhz ECC/non-ECC, un-buffered memory
NOTE: Actual Memory data rate varies on CPU
|Expansion Slots||1 x PCIe 4.0 (x16 Speed)
1 x PCIe 4.0 x16 (x4 Speed)
1 x PCIe 3.0 x16 (x2 Speed)
|Onboard Graphics||1 x HDMI
NOTE: Display support varies on CPU
|Storage||4 x SATA 6Gb/s
1 x M.2 Key M, 25110/2280, (PCIe 5.0 x4 Mode)
3 x M.2 Key M, 22110/2280, (PCIe 4.0 x4 Mode)
|RAID||SATA Devices: RAID 0/1/10|
|USB Rear I/O||1 x USB 3.2 Gen2x2 Type-C|
2 x USB 3.2 Gen2 Type-A
6 x USB 3.2 Gen1 Type-A
4 x USB 2.0 Type-A
|USB Internal Connectors||1 x USB 3.2 Gen2x2 Type-C
4 x USB 3.2 Gen 1 Type-A (2 per header)
4 x USB 2.0 Type-A (2 per header)
|Thunderbolt||1 x THB_U4 add-in card connector|
|RGB LED Connectors||1 x CPU cooler LED strip/RGB LED strip header
2 x addressable LED strip headers
2 x RGB LED strip headers
|Audio||Realtek Audio Codec
8-Channel (7.1) HD Audio
|LAN||1 x Realtek RTL8125 2.5Gbps LAN controller|
|WIRELESS||AMD 2x2 WIFI 6E RZ616
WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
|Back Panel Connectors||1 x HDMI
2 x Antenna connectors
6 x USB 3.2 Gen 1 Type-A ports (blue)
2 x USB 3.2 Gen 2 Type-A ports (red)
1 x USB 3.2 Gen 2x2 Type-C Port 4 x USB 2.0/1.1 ports
1 x Q-Flash Plus button
1 x RJ-45 port
3 x audio jacks
|Internal Connectors||1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
1 x CPU fan header
1 x water cooling CPU fan header
3 x system fan headers
1 x CPU cooler LED strip/RGB LED strip header
2 x addressable LED strip headers
2 x RGB LED strip headers
4 x SATA 6Gb/s connectors
4 x M.2 Socket 3 connectors
1 x front panel header
1 x front panel audio header
1 x USB Type-C® header, with USB 3.2 Gen 2x2 support
2 x USB 3.2 Gen 1 headers
2 x USB 2.0/1.1 headers
1 x THB_U4 add-in card connector
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
1 x power button
1 x reset button
1 x Clear CMOS button
1 x reset jumper
1 x Clear CMOS jumper
305mm x 244mm
