500GB, 4 x Sony CCD BNC Cameras, Night Vision, Indoor / Outdoor
Sorry, this product is no longer available to purchase.
Video Format | Both |
Video Inputs | 4 x Composite BNC Inputs |
Video Outputs | 2 x Composite BNC Outputs |
Display Resolution | NTSC: 704 x 480 / PAL: 704 x 576 |
Display Frame Rate | NTSC: 120fps / PAL: 100fps |
Audio Input | 1 x RCA Input |
Audio Output | 1 x RCA Output |
Compression Format | H.264 |
Recording Resolution | NTSC: 704 x 480 (D1), 704 x 240 (HD1), 352 x 240 (CIF)
PAL: 704 x 576 (D1), 704 x 288 (HD1), 352 x 288 (CIF) |
Recording Frame Rate | NTSC: 30 fps (D1), 60 fps (HD1), 120 fps (CIF)
PAL: 25 fps (D1), 50 fps (HD1), 100 fps (CIF) |
Recording Modes | Manual / Schedule / Motion |
Multiplex Operation | Triplex |
HDD Interface / Memory Type | SATA |
Hard Drive Support | Up to 1TB |
LAN Connection | Yes |
Network Interface | RJ45 |
Network Protocol | TCP/IP, DDNS, UPnP |
Remote Operation | Yes |
Operating Power | DC 12V |
Dimensions | 250mm x 220mm x 40mm |
Weight | 1.5kg |
Back-up Method | USB to Flash Drive |
Mouse Support | Yes |
Remote Control | Yes |
Remote Control Battery | 2 x AAA |
Image Sensor | 1/4" Sony CCD |
Video Quality | 480 TV Lines |
Number of Effective Pixels | NTSC: 510 x 492 / PAL: 628 x 582 |
Minimum Illumination | 0 Lux (IR on) |
Day/Night Mode | Color during day / switches to B&W at night |
White Balance | Automatic |
Signal / Noise Ratio | > 50dB |
Electronic Shutter | NTSC: 1/60 - 1/100,000
PAL: 1/50 - 1/100,000 |
Gain Control | Automatic |
Backlight Compensation | Yes |
Wide Dynamic Range | No |
Lens | 3.66mm |
Viewing Angle | 62 Degrees |
Microphone | N/A |
Audio Range | N/A |
Night Vision Distance | Up to 65ft / 20m |
IR Cut Filter | No |
Number of Infra-Red LEDs | 12 |
Infra-Red Wavelength | 850nm |
Infra-Red LED Life | 10,000 hours |
Indoor / Outdoor | Both |
Operating Power | DC 12V |
Operating Temperature | -4 degrees F~ 113 degrees F
-20 degrees C ~ 45 degree C |
Body Construction | Aluminum |
Dimensions - Camera & Stand | N/A |
Dimensions - Camera | 82mm x 58mm x 55mm |
Dimensions - Stand | 50mm x 50mm x 70mm |
Weight - Camera | 203g |
Weight - Camera & Stand | 286g |
Cable Length | 18m |
